Mini Dumper
Features
1.pilot control,easy to operate, easy to operate.
2.rubber tracks,strong traction,enhanced shock absorption.
3.hydraulic hose, high-pressure explosion-proof oil hose.
4.electrophoretic spray paint, the paint surface is smooth and not easy to rust
Mini dumper, also known as a power barrow or mini dump truck, is a compact and versatile piece of equipment used for transporting materials over short distances in construction, landscaping, agriculture, and other industries. Mini dumpers are designed to handle small to medium loads of materials such as soil, gravel, sand, construction debris, and more, making them ideal for navigating through tight spaces and rough terrain.
Parameter
Engine parameter | Brigss&Stratton | Hydraulic oil No. | 46# anti-wear hydraulic oil |
Total power | 6.5HP | Hydraulic tank capacity | 7L |
Cylinder | 1 | Climbing capacity | 20° |
Ingestion | Natural inhalation | Minimum ground clearance | 85mm |
Emission standard | Euro 5/EPA | Minimum turning radius | 950mm |
Fuel capacity | 3.5L | Track center distance | 520mm |
Oil capacity | 0.6L | Travel speed | 1.7/3.5 (km/h) |
LxW xH | 1517x870x1278mm | Maximum torque of traveling motor | 805Nm |
Container volume | 0.22m3 | Maximum working pressure of walking motor | 20MPa |
Vehicle weight | 400Kg | Travelling motor displacement | 200cc |
Maximum load | 500Kg | Walking motor brand | Liko Hydraulic |
